Omega deduction

Description

The Omega pull-off unit serves as a belt drive in the production of composite pipes. It pulls the metal strip from the reel through the upstream system components. A dancer roller keeps the strip taut by its own weight.
The position of the dancer roller is detected via a displacement sensor and regulates the belt speed or adjusts it to the speed of a following drive.

Advantages:

    • Easy to use
    • Constant tape deduction
    • Optimal train control
    • Compact design

      Technical data:

        • Maximum bandwidth: 250 mm
        • Minimum band thickness: 0.12 mm
        • Maximum band thickness: 2.5 mm
