Strip Feeding Lines

Our strip feeding systems stand for the highest precision, maximum process stability and a continuous material supply – specially developed for thin strip materials in coil format with thicknesses from 0.02 mm to 2.0 mm.


As specialists in the handling and processing of sensitive thin strips, we develop and manufacture modular systems precisely tailored to the requirements of modern production lines. Our focus is on gentle, reliable, and highly automated feeding of the strip material – even with demanding materials and tight tolerances.


Our belt feeding systems are based on a flexible, modular system and consist – depending on requirements – of:


  • Unwinder for different coil weights and diameters
  • Laser strip welding machine for reliable joining of strip ends
  • Straightening device for optimal band flatness (if necessary)
  • Strip accumulator/storage for uninterrupted material supply
  • Omega drive station including dancer control for optimal belt tension


Thanks to the modular design, our systems can be individually adapted to material, production speed and spatial conditions with minimal effort.


Bandzuführung

STRIP FEEDING LINES

Advantages of our systems:

  • Individual components are optimally matched to each other
  • Easy operation thanks to integrated control for the entire line
  • High precision at high line speeds of up to 120 m/min
  • Developed by practitioners for practitioners
  • Modular system on adjustable base frames
  • Stable steel structures
  • compact design
  • easy handling
  • high production reliability
  • Industry 4.0
  • Line controlling using the data store and the fault control system
    •

    STRIP FEEDING LINES

    Technical data:

  • Line speed: up to 120m/min
  • Bandwidth: max. 650mm
  • Wall thicknesses:0.02mm - 2.0mm (depending on material)
  • Strip materials: Aluminum, steel, stainless steel, copper, coated strips, various alloys
  • Plant control: Siemenss 1500
  • Operation: 18.5" HMI
  • Tape storage capacity: Design according to speed

    • Construction of the belt feeding systems:

    1. Double Uncoiler

    Two unwind reels supply the line with strip material. The strip change can be prepared in advance to minimize downtime.

    2. Straigthening Unit

    The straightening machine removes strip curvature and residual stresses. This ensures that the material enters the subsequent stations in a stable and reliable manner.

    3. Laser Strip Welding Machine

    The ends of the strips are welded together using a laser. This creates a reproducible, high-strength connection for continuous line operation.

    4. Strip Accumulator

    The belt storage buffers belt material between the unwinders and the process. This allows production to continue during belt changes or welding.

    5. Omega Drive Machine incl. Dancer Control

    The belt tensioner ensures constant belt tension and a consistent material flow. The dancer control compensates for tension fluctuations and stabilizes the process.

    Overall system:

    Verbundrohranlage

    Standard Line Types (dimensions):

    • TSM 120 - Bandwidths up to 120mm

      • Strip material: copper, stainless steel, steel, aluminum, brass, coated strips
      • Max. strip thickness: 0.5 mm (material dependent)
      • Max. strip width: 120 mm
      • Storage capacity: up to 250 m
      • Production speed: up to 120 m/min
        •

    • TSM 200 - Bandwidths up to 200mm

      • Strip material: copper, stainless steel, steel, aluminum, brass, coated strips
      • Max. strip thickness: 0.8 mm (material dependent)
      • Max. strip width: 200 mm
      • Storage capacity: up to 160 m
      • Production speed: up to 80 m/min
        •

    • TSM 350 - Bandwidths up to 350

      • Strip material: copper, stainless steel, steel, aluminum, brass, coated strips
      • Max. strip thickness: 1.5 mm (material dependent)
      • Max. strip width: 350 mm
      • Storage capacity: 80 m
      • Production speed: up to 30 m/min
        •

    • TSM 650 - Bandwidths up to 650mm

      • Strip material: copper, stainless steel, steel, aluminum, brass, coated strips
      • Max. strip thickness: 2mm (material dependent)
      • Max. strip width: 650mm
      • Storage capacity: 30m
      • Production speed: up to 20m/min
        •

    * We naturally implement custom-designed belt feeding systems for other applications.
